Contactor, Definite Purpose, 30A, 2 pole, 110/120VAC 50/60Hz coil, open

Product or Component Type

Definite Purpose Contactor

Line Rated Current

30 A

Number of Poles

2P

Pole contact composition

2 NO

Range of Product

DP

Maximum Horse Power Rating

2 hp 115 V AC, 1 phase
5 hp 230 V AC, 1 phase

Locked rotor rated current

125 A 460 V AC
100 A 575 V AC
150 A 277 V AC

[Ue] rated operational voltage

600 V AC

[Uc] control circuit voltage

120 V AC 60 Hz
110 V AC 50 Hz

Phase

1 phase

Electrical Connection

Binder head
Quick connect terminals

Product Certifications

UL Recognized
CSA

Category

US1CP1B21356

Discount Schedule

CP1B

GTIN

785901073338

Returnability

Yes

Country of origin

CN

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

2.600 in (6.604 cm)

Package 1 Width

3.400 in (8.636 cm)

Package 1 Length

2.300 in (5.842 cm)

Package 1 Weight

9.600 oz (272.155 g)

Unit Type of Package 2

CAR

Number of Units in Package 2

12

Package 2 Height

5.800 in (14.732 cm)

Package 2 Width

7.100 in (18.034 cm)

Package 2 Length

7.200 in (18.288 cm)

Package 2 Weight

7.531 lb(US) (3.416 kg)

Warranty

18 months
