APC Smart-UPS, Line Interactive, 2200VA, Rackmount 2U, 120V, 6x NEMA 5-15R+2x NEMA 5-20R outlets, SmartSlot, AVR, LCD, W/L5-20P

Lead time

Usually Ships within 3 Weeks

Main Input Voltage

120 V

Main Output Voltage

120 V

Kw Rating

1920 W

Rated power in VA

1920 VA

Product or Component Type

Uninterruptible power supply (UPS)

Input Connection Type

NEMA L5-20P

output connection type

6 NEMA 5-15R
2 NEMA 5-20R

Number of rack unit

2U

Cable length

8 ft (2.4 m)

Number of cables

1

Battery Type

Lead-Acid battery

Provided equipment

CD with software
Documentation CD
Rack Mounting brackets
Rack Mounting support rails
Smart UPS signalling RS-232 cable
USB cable

Run Time

View Runtime Graph

Efficiency

View Efficiency Graph

Extendable Run Time

0

Included Battery Modules

0

Battery Slots Empty

0

Typical recharge time

3 h

RBC Quantity

1

Battery Life

3…5 year(s)

Replacement battery

RBC43

Battery Charge Power (Watts)

164 W rated

Number of power module filled slots

0

Number of power module free slots

0

Redundant

No

color

Black

Height

3.4 in (8.6 cm)

Width

18.9 in (48 cm)

Depth

26.9 in (68.3 cm)

Net Weight

93.28 lb(US) (42.31 kg)

mounting location

Front

Mounting preference

Lower

Mounting Mode

Rack-mounted

Two post mountable

0

USB compatible

Yes

Efficiency at full load

75...154 V adjustable
82...143 V

Input Frequency

50/60 Hz +/- 3 Hz auto-sensing

Harmonic distortion

Less than 5%

Maximum configurable power in VA

2200 VA

Max Configurable Power (Watts)

1980 W

Transfer Time

4ms typical : 8ms maximum

Topology

Line Interactive

Wave type

Sine wave

Output Frequency (sync to mains)

50/60 Hz +/- 3 Hz sync to mains

Product Certifications

CSA

Equipment protection policy

Lifetime : $150000

Acoustic level

55 dBA

heat dissipation

215 Btu/h

Operating altitude

0...10000 ft

Ambient Air Temperature for Operation

32…104 °F (0…40 °C)

Ambient Air Temperature for Storage

5…113 °F (-15…45 °C)

Storage altitude

0…50000 ft (0…15240 m)

Relative Humidity

0…95 %

Storage Relative Humidity

0…95 %

control panel

Multi-function LCD status and control console

Emergency Power Off (EPO)

Yes

Free slots

1

Alarm

Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm

Surge energy rating

530 J

GTIN

731304294085

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

10.0 in (25.4 cm)

Package 1 Width

38.6 in (98 cm)

Package 1 Length

23.6 in (60 cm)

Package 1 Weight

109.64 lb(US) (49.73 kg)

Warranty

3 years repair or replace (excluding battery) and 2 years for battery
