APC Smart-UPS, Line Interactive, 1500VA, Tower, 120V, 8x NEMA 5-15R outlets, SmartConnect Port+SmartSlot, Audible alarm disabled, AVR, LCD

Lead time

Usually in Stock

Main Input Voltage

120 V

Main Output Voltage

120 V

Kw Rating

1000 W

Rated power in VA

1440 VA

Product or Component Type

Uninterruptible power supply (UPS)

Input Connection Type

NEMA 5-15P

output connection type

8 NEMA 5-15R

Cable length

6 ft (1.8 m)

Number of cables

1

Battery Type

Lead-Acid battery

Provided equipment

Installation guide

Run Time

View Runtime Graph

Efficiency

View Efficiency Graph

Extendable Run Time

0

Included Battery Modules

0

Battery Slots Empty

0

Typical recharge time

3 h

RBC Quantity

1

Battery Life

3…5 year(s)

Battery Charge Power (Watts)

136 W rated

Number of power module filled slots

0

Number of power module free slots

0

product web sub-family

Cloud-enabled monitoring

Redundant

No

Variant option

Audible alarm disabled (can be re-enabled by user)

color

Black

Height

8.6 in (21.9 cm)

Width

6.7 in (17.1 cm)

Depth

17.3 in (43.9 cm)

Net Weight

54.2 lb(US) (24.6 kg)

mounting location

Front

Mounting preference

No preference

Mounting Mode

Not rack-mountable

Two post mountable

0

USB compatible

Yes

Efficiency at full load

75...154 V adjustable

Input Frequency

50/60 Hz +/- 3 Hz auto-sensing

Harmonic distortion

Less than 5%

Maximum configurable power in VA

1440 VA

Max Configurable Power (Watts)

1000 W

Transfer Time

6ms typical : 10ms maximum

Topology

Line Interactive

Wave type

Sine wave

Output Frequency (sync to mains)

50/60 Hz +/- 3 Hz sync to mains

Product Certifications

cULus
ENERGY STAR V2.0 (USA)

Acoustic level

45 dBA

heat dissipation

140 Btu/h

Operating altitude

0...10000 ft

Ambient Air Temperature for Operation

32…104 °F (0…40 °C)

Ambient Air Temperature for Storage

5…113 °F (-15…45 °C)

Storage altitude

0…50000 ft (0…15240 m)

Storage Relative Humidity

0…95 %

control panel

Multi-function LCD status and control console

Emergency Power Off (EPO)

Optional

Free slots

1

Alarm

Alarm when on battery : distinctive low battery alarm : configurable delays

Surge energy rating

680 J

Filtering

Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : m

GTIN

731304426325

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

8.6 in (21.9 cm)

Package 1 Width

17.3 in (43.9 cm)

Package 1 Length

6.7 in (17.1 cm)

Package 1 Weight

54.2 lb(US) (24.6 kg)

Warranty

3 years repair or replace (excluding battery) and 2 years for battery
