APC Smart-UPS, Line Interactive, 1000VA, Lithium-ion, Rack/Tower, 2U, 230V, 6x IEC C13 outlets, SmartConnect Port+SmartSlot, Short Depth, AVR, LCD

Presentation

Intelligent and efficient network power protection from entry level to scalable runtime. Ideal UPS for servers, point-of-sale, routers, switches, hubs and other network devices.

Lead time

Usually in Stock

Main Input Voltage

230 V

Other Input Voltage

220 V
240 V

Main Output Voltage

230 V

Other Output Voltage

220 V
240 V

Kw Rating

800 W

Rated power in VA

1000 VA

Product or Component Type

Uninterruptible power supply (UPS)

Input Connection Type

IEC 60320 C14

output connection type

6 IEC 60320 C13

Number of rack unit

2U

Battery Type

Li-Ion (Lithium Ion)

Provided equipment

Installation guide
Rack Mounting support rails
USB cable

Software package

SmartConnect software for remote power monitoring feature availability varies by terms of use

Run Time

View Runtime Graph

Efficiency

View Efficiency Graph

Battery graph comments

This graph is based on actual measured runtime data. All measurements were taken with new, fully charged batteries and a balanced resistive load (PF = 1.0). Actual runtimes may vary from the values of this graph. Actual runtimes are dependent on several variables including battery age, battery charge level, environmental conditions and characteristics of the connected load.

Extendable Run Time

0

Typical recharge time

3 h

Battery design life

8…10 year(s)

Battery Charge Power (Watts)

79 W rated

product web sub-family

Cloud-enabled monitoring

Redundant

No

color

Black with silver front bezel

Height

3.4 in (8.6 cm)

Width

17.2 in (43.8 cm)

Depth

12.5 in (31.8 cm)

Net Weight

35.9 lb(US) (16.3 kg)

Mounting preference

Lower

Mounting Mode

Rack-mounted

USB compatible

Yes

Input protection type

Circuit breaker

Efficiency at full load

151...302 V adjustable
160...280 V

Input Frequency

50/60 Hz +/- 3 Hz auto-sensing

Crest factor

3 : 1

Harmonic distortion

Less than 5%

Maximum configurable power in VA

1000 VA

Max Configurable Power (Watts)

800 W

Transfer Time

6ms typical : 10ms maximum

Topology

Line Interactive

Wave type

Sine wave

Output Frequency (sync to mains)

50/60 Hz +/- 3 Hz sync to mains

Product Certifications

C-tick
CE
EAC
RCM
UK PSTI

Standards

EN/IEC 62040-2:2006/AC:2006
EN/IEC 62040-2:2018

Acoustic level

41 dBA

heat dissipation

70 Btu/h

Operating altitude

0...10000 ft

Ambient Air Temperature for Operation

32…104 °F (0…40 °C)

Ambient Air Temperature for Storage

5…113 °F (-15…45 °C)

Storage altitude

0…25000 ft (0.0000000000…7620.0000000000 m)

IP degree of protection

IP20

Relative Humidity

0…95 % non-condensing

Storage Relative Humidity

0…95 % non-condensing

Audible Alarm

Audible and visible alarms

control panel

Multi-function LCD status and control console

Free slots

1

Communication port support

SmartConnect Ethernet port: for cloud monitoring feature availability varies by terms of use

Alarm

Alarm when on battery : distinctive low battery alarm

Surge energy rating

680 J

Filtering

Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : m

GTIN

731304402596

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

9.02 in (22.9 cm)

Package 1 Width

18.6 in (47.2 cm)

Package 1 Length

23.0 in (58.4 cm)

Package 1 Weight

41.006 lb(US) (18.6 kg)

Warranty

5 year repair or replace
