APC Back-UPS 675VA, 120V, 1 USB charging port, 7 NEMA outlets (2 surge)
SKU: BE670M1
Overview
Lead time
Usually in Stock
Main
Main Input Voltage
120 V
Main Output Voltage
120 V
Kw Rating
360 W
Rated power in VA
675 VA
Product or Component Type
Uninterruptible power supply (UPS)
Input Connection Type
NEMA 5-15P
output connection type
5 NEMA 5-15R
2 NEMA 5-15R surge
Cable length
5 ft (1.5 m)
Battery Type
Lead-Acid battery
Provided equipment
User Manual
Batteries & Runtime
Run Time
View Runtime Graph
Efficiency
View Efficiency Graph
Included Battery Modules
1
Battery Slots Empty
0
Typical recharge time
10 h
RBC Quantity
1
Battery Charge Power (Watts)
7 W rated
Battery power in VAH
66 VAh runtime
Battery Life
3…5 year(s)
Replacement battery
APCRBC154
Extendable Run Time
0
General
Number of power module free slots
0
Number of power module filled slots
0
Redundant
No
Physical
Height
5.5 in (13.9 cm)
Width
10.8 in (27.4 cm)
Depth
4.1 in (10.5 cm)
Net Weight
7.69 lb(US) (3.49 kg)
Mounting preference
No preference
Mounting Mode
Not rack-mountable
Two post mountable
0
USB compatible
No
Input
Input Frequency
50/60 Hz +/- 3 Hz auto-sensing
Efficiency at full load
92...139 V
Output
Max Configurable Power (Watts)
360 W
Output Frequency (sync to mains)
50/60 Hz +/- 3 Hz sync to mains
Topology
Standby
Wave type
Stepped approximation to a sinewave
Maximum configurable power in VA
675 VA
Transfer Time
6ms typical : 10ms maximum
Conformance
Product Certifications
California (CEC) Battery Charger
cTUVus
NOM
Equipment protection policy
Lifetime : $75000
Environmental
Ambient Air Temperature for Operation
32…104 °F (0…40 °C)
Relative Humidity
0…90 %
Operating altitude
0...10000 ft
Ambient Air Temperature for Storage
5…113 °F (-15…45 °C)
Storage Relative Humidity
0…95 %
Storage altitude
0…50000 ft (0…15240 m)
Acoustic level
35 dBA
heat dissipation
16 Btu/h
Communications & Management
Alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Surge Protection and Filtering
Surge energy rating
490 J
Filtering
Full time multi-pole noise filtering :5% of IEEE surge let-through : zero clamping response time: in
Let Through Voltage Rating
5 V
Ordering and shipping details
GTIN
731304341925
Packing Units
Unit Type of Package 1
PCE
Number of Units in Package 1
1
Package 1 Height
7.7 in (19.6 cm)
Package 1 Width
6.6 in (16.8 cm)
Package 1 Length
14.3 in (36.3 cm)
Package 1 Weight
8.40 lb(US) (3.81 kg)
SCC14
10731304341922
Contractual warranty
Warranty
3 years repair or replace
Enter your zip code to see prices
Delivery of products may differ based on your Zip code

<a>Replacement battery (1)</a> is available
Compact size acommodates installation in a variety of environments
Data line protection ensures complete protection of your equipment from surges
